- High-Availability via multiWAN Auto-Failover/Fallback between LTE-A & GE-WAN ensure connectivity always-on
- Supports various VPN technologies for secure & flexible connection
- Gigabit Ethernet LAN & AC1200 WiFi supports MU-MIMO technology enhance wireless performance & experience
WAN interfaces
- LTE SIM interface
- 10/100/1000Mbps Ethernet interface
Multi-WAN Features
- WAN priority configuration
- Automatically Failover/Fallback between WAN interfaces
Advanced Dual Band Wireless
- 802.11ac wave2 (Multi‐User) MU‐MIMO ready
- 5G 802.11a/n/ac support up to 866Mbps
- 2.4G 802.11b/g/n support up to 300Mbps
- 2T2R MIMO technology
- WPS for easy setup
- AP neighbors scan
- Wireless access control
- WiFi security: WEP, WPA, WPA2
- Multiple‐SSID
- Virtual AP/SSID isolation
- WMM (WiFi Multimedia)
Network Security
- Build‐in robust Firewall
- NAT/NAPT
- Stateful Packet Inspection (SPI)
- IP/service ports/MAC packet filtering
- URL/Domain filtering
- DHCP server, client & relay
- Port Forwarding
- Virtual server
- DMZ
- DoS Protection
- ALG, ACL
- PPTP/L2TP/IPSec VPN pass‐through
Virtual Private Network (LR7281S)
- IPSec VPN
- L2TP over IPSec VPN server
- L2TP over IPSec client
- PPTP VPN server
- PPTP VPN client
- OpenVPN server
- OpenVPN client
Management
- LTE connectivity info
- LAN/WLAN clients info
- Interface statistics
- ARP table
- CWMP/TR‐069 Remote Management
- Web‐based GUI configuration
- Firmware upgrades through HTTP
- Syslog
- Configuration File Backup and Restore
- SNMP v1/v2
Network Protocol
- Bridged, PPPoE, IPoE
- Static route
- RIP v1/v2
- MTU size adjustment
- Port mapping
- QoS (Quality of Service) classification
- DNS proxy/relay,
- DDNS
- NTP client
- UPnP
- IGMP snooping & proxy
- MLD snooping & proxy
IPv6 Ready
- IPv6 static routing
- IPv6 dual‐stack
- RADVD
- DHCP v6
- IPv6 IP filtering
- IPv6 MLD snooping & proxy
Physical Interface
- 1x SIM slot for LTE
- 1x Gigabit‐Ethernet WAN port (RJ45)
- 4x Gigabit‐Ethernet LAN Ports (RJ‐45)
- 1x USB
- 1x Reset button
- 1x WPS button
- 1x WiFi on/off
- 1x Power jack
- 1x Power on/off switch
Power
- 12V DC/1.5A
Operating Environment
- Operating temperature: 0 – 40°C
- Storage temperature: ‐20 – 70°C
- Humidity: 20 – 95% non‐condensing
Ordering Information
- LR7281‐BQ4
LTE Cat.4 – B1/2/3/5/7/8/20/38/40
WCDMA/UMTS – B1/2/5/8
- LR7281‐Q26
LTE-A Cat.6 – B1/3/7/8/20/28/38/40/41
WCDMA/UMTS – B1/3/5/8
- LR7281S‐BQ4
Support VPN connection
LTE Cat.4 – B1/2/3/5/7/8/20/38/40
WCDMA/UMTS – B1/2/5/8
- LR7281S‐Q26
Support VPN connection
LTE-A Cat.6 – B1/3/5/7/8/20/28/38/40/41
WCDMA/UMTS – B1/3/5/8
