- Cost-Effective ADSL2+ solution
- N300 2x2 802.11n Wireless
- TR069/CWMP, SNMP and WebGUI management
DSL
- ANSI T1.413 Issue 2
- G.992.1 (G.dmt)
- G.992.2 (G.lite)
- G.992.3 (ADSL2/G.bis)
- G.992.5 (ADSL2+)
PPP/ATM
- PPP over ATM PVC (RFC 2364)
- PPP over Ethernet (RFC 2516)
- PPPoE pass through, Point-to-Point (PPP) over AAL5 (RFC 2364)
- Classical IP over ATM (RFC 2225), PAP, CHAP, MS-CHAP authentication, Multiple Service PVC
Networking
- NAT/NAPT, IEEE 802.1d transparent bridging
- Static route, RIP v1/v2, IGMP Proxy v1/v2
- IGMP snooping v1/v2, IP/Bridge/802.1p QoS, DHCP Server/Client/Relay, UPnP, HTTP, FTP, TFTP, Telnet
2.4GHz Wireless
- 802.11b/g/n support up to 300Mbps (2T2R) in 2.4GHz
- 802.1x, WPA/WPA2, WPA-PSK/WPA2-PSK, MAC Filter, WPS
Firewall/Security
- IP / Port Filtering, MAC Filtering
- Denial of Service (DOS), SPI firewall, DMZ
Configuration/Management
- Web configuration interface, Firmware upgrades through HTTP, Configuration File Backup and Restore, TR-069
Interface
- 1x xDSL Port (RJ-11)
- 4x FE Ports
- 1x USB (Optional, for LTE dongle support, Multi-WAN)
- 1x Reset button for factory default reset
- 1x WPS button
- 1x WiFi on/off
- 1x Power jack
- 1x Power on/off switch
- 2x External fixed antennas
Power Supply
- 12V DC/1A
Operation Temp.
- 0~40 C
