GPON

• ITUT G.984.1/G.984.2/G.984.3/G.984.4/G.984.5
• DS/US rate up to 2.488Gbps/1.244Gbps
• Wavelength: DS 1490nm and US 1310nm
• DBA, FEC, 802.1p Flexible mapping between GEM ports and T-CONT

VoIP

• SIP(RFC3261)
• RTP/RTCP
• SDP
• G.711(A-law, u-law)
• G.726
• G.729
• G.723.1
• G.729A
• Echo Cancellation
• RTP
• Call Forward
• Call Transfer
• Call Hold
• Call waiting
• VAD
• CNG
• Caller ID
• T.38 FAX
• Dial Plan

Networking

• PPPoE/DHCP/Static
• DHCP server
• DNS Relay
• NAT/NAPT
• Port Fowarding
• Static Route
• ACL
• VPN pass-through
• Firewall
• ALG
• DDNS
• DMZ
• NTP
• uPnP
• IGMP Proxy
• IPv6
• IEEE 802.1d bridging
• VLAN QinQ
• VLAN translation
• 802.1p
• IGMP Snooping
• Broadcast/Multicast rate limiting

2.4GHz Wireless

• 802.11b/g/n support up to 300Mbps (2T2R) in 2.4GHz
• 802.1x
• WPA/WPA2
• WPA-PSK/WPA2-PSK
• MAC Filter
• WPS

5GHz Wireless

• 802.11/n/ac support up to 1200Mbps (2T2R) in 5GHz
• 802.1x
• WPA/WPA2
• WPA-PSK/WPA2-PSK
• MAC Filter
• WPS

Configuration/Management

• OMCI(G.988), TR-069, Web configuration interface, Configuration File Backup and Restore
• Interface
• 1x GPON Port
• 2x FXS Ports
• 4x GE LAN Ports
• 1x USB for Storage
• 1x Reset button for factory default reset
• 1x WPS button
• 1x WiFi On/Off button
• 1x Power jack
• 1x Power on/off switch

Power Supply

• 12V DC/1.5A

Operating Temp.

• -5~40 C
